SPECIFICATIONS

Application: Desktop

Audio Channels: 5.1

Back I/O Ports: 1x RJ45,PS/2

Battery Included: No

Brand Name: SOYO

Chipset: C612

Chipset Manufacturer: Intel

Choice: yes

Form Factor: Micro-ATX

High-concerned chemical: None

Maximum Ram Capacity: 128 GB

Memory channel: Double

Number Of Memory Slots: 4

Number of M.2: 2

Number of PCI: 2

Number of PCIe x 16: 1

Number of PCIe x 4: 0

Number of PCIe x 8: 0

Number of SATA Ports: 4

Onboard Connectors & Header: 24-pin Main Power Connector

Onboard LAN: 1x RJ45

Origin: Mainland China

PCI – E standards: PCI-E 3.0

Package: Yes

Ports: USB 3.0

Processor compatibility: Intel Xeon E Series

RAID Supported: Yes

Socket Type: LGA 2011-3

Special Features: Cooling Armor

Storage Interface Type: SATA,M.2 (NVMe),M.2 (SATA)

Support Memory Type: DDR4

Support USB Type: USB 2.0,USB 3.0

Supports M.2 SSD: 2242,2280

Usage Scenario: Enthusiast & Overclocking,Gaming,Audio & Video,Office,Video Production

With CPU: No

Notice：

ALL RAM needs to install in slot (grey slot)priority

The package does not include CR2032 batteries

Attention: A 2032 battery needs to be installed to start the computer, otherwise it cannot be started

If inserted in the wrong location, it can cause the computer to not start.

**Product Specifications**

**Supports TPM2.0**

**Chipset**

Intel C612

**CPU**

– Intel Xeon E5 LGA2011-V3 socket processors

– Supported models: E5-2603V3, 2666V3, 2673V3, 2680V3, 2678V3, 2696V3, 2684V4, 2696V4, etc.

**Memory**

– 4 x DDR4 DIMM slots

– Supports 2133/2400MHz (Max), up to 128GB (32GB x 4)

– Gray slots indicate primary channels

**Storage**

– 2 x M.2 slots:

– **Upper slot**: NVMe protocol (PCIe 3.0 x4/SATA3.0)

– **Lower slot**: NVMe protocol (PCIe 3.0 x4)

– 4 x SATA3.0 interfaces

**TPM**

– 1 x 14-pin header (compatible with MSI 14-pin/TPM 2.0 module)

**Networking**

– 1 x RJ45 port

– **LAN chip**: Realtek RTL8111H Gigabit Ethernet

**PS/2 Ports**

– 1 x PS/2 Keyboard port

– 1 x PS/2 Mouse port

**Audio**

– Rear I/O: 1 x Line Out, 1 x MIC In, 1 x Line In

– Internal header: 1 x Front Audio header

– **Audio chip**: Realtek ALC897 HD Audio

**USB Ports**

– Rear I/O: 2 x USB 2.0, 4 x USB 3.0

– Internal headers:

– 1 x USB 2.0 header (expandable to 2 ports)

– 1 x USB 3.0 header (expandable to 2 ports)

**PCIe Slots**

– **PCIe1**: PCIe x16 3.0 slot (from CPU)

– **PCIe2**: PCIe x1 2.0 slot (from PCH)

**Functional Headers**

– 1 x FPANEL (front panel)

– 1 x 4-pin CPU fan

– 1 x 3-pin system fan

– 1 x JBAT (CMOS clear)

– 1 x JLPC (LPC debug)

– 1 x SPEAK (system speaker)

**Power Input**

– 24-pin ATX + 8-pin EPS connectors

**Dimensions**

– 220 x 190mm (4-layer PCB)
